Mean Well IRM-60-24ST AC/DC-Druckstrømforsyning 60 W
Artikelnummer: [4264119] | Produzent: Mean Well | Modell nummer: IRM-60-24ST | EAN: 4021087028103
Externen Lager (16-23 Werktage)
Das Produkt befindet sich in einem externen Lager. Die Lieferfrist: ca. 16-23 Werktage. Mehr Info
Versandoptionen - Wird im Checkout ausgewählt
Versand mit DHL - PaketShop
3,57
Versand mit DHL zur Adresse
7,60
Versand mit GLS - PaketShop
9,16
Versand mit GLS zur Adresse
11,90
Alle Versandoptionen anzeigen (4)
EUR
40,45
ex. MwSt. 33,99
Gesamtbetrag inkl. Versand.
44,02
Zur Liste hinzufügen
Die Funktion setzt voraus, dass Sie angemeldet sind. Erstellen Sie einen Nutzer und verwenden Sie unser intelligentes Listensystem, um zukünftige Einkäufe, regelmäßige Einkäufe oder Wunschlisten zu verfolgen.
Send på mail
Mean Well Encapsulated Switch Mode Power Supply
The Mean Well IRM-60 series 60W single output AC to DC encapsulated switch-mode power supply has an output current rating of 2.5A at 24VDC. It has a universal input supply voltage rating ranging from 85VAC to 264VAC and 120VDC to 370VDC. The power supply meets anti-vibration demand up to 5G capability. It provides resistance to dust and moisture while enhancing heat dissipation. It has a compact output solution and is ready to solder straight onto PCB boards. The power supply has a Class II design and includes built-in EMI filtering components along with excellent EMC features that prevent electromagnetic interference.
Features and Benefits
Highly versatile
Low no-load power consumption below 0.1W
High efficiency up to 87.5%
Compact size
Overvoltage
Overload and short circuit protection
Cooled by free air convection
Full load burn-in test 100%
High reliability
screw terminals
Applications
Hand held electronic devices
Factory automation equipment
Mechanical equipment
Industrial electrical equipment
Certifications
UL60950-1
TUV approved
EN60950-1 approved
EN55022 (CISPR22) class B
EN61000-3-2,-3
EN61000-4-2,3,4,5,6,8,11
EN55024
Heavy industry level (surge L-N: 1KV)
Criteria A
Note
Available on EPLAN.
