BlueOptics SFA21BK2, 2 dB, Silber, LC, -40 - 75 °C
Artikelnummer: [9768569] | Produzent: BLUEOPTICS | Modell nummer: SFA21BK2 | EAN: 4063232044576
Externen Lager (16-23 Werktage)
Das Produkt befindet sich in einem externen Lager. Die Lieferfrist: ca. 16-23 Werktage. Mehr Info
Versandoptionen - Wird im Checkout ausgewählt
Versand mit DHL - PaketShop
3,57
Versand mit DHL zur Adresse
11,90
Versand mit GLS - PaketShop
9,16
Versand mit GLS zur Adresse
11,90
Alle Versandoptionen anzeigen (4)
EUR
30,71
ex. MwSt. 25,81
Gesamtbetrag inkl. Versand.
34,28
Die Funktion setzt voraus, dass Sie angemeldet sind. Erstellen Sie einen Nutzer und verwenden Sie unser intelligentes Listensystem, um zukünftige Einkäufe, regelmäßige Einkäufe oder Wunschlisten zu verfolgen.
Jetzt registrieren
Anmelden
Jetzt registrieren
Anmelden
Send på mail
Optimal Fiber Connections
BlueOptics© SFA21BK2 2dB Fiber Optic Attenuator for single-mode (9/125µm) fiber links G.652.D (from 1270nm to 1610nm) from CBO, with LC/PC Simplex connector and highly reliable ceramic ferrule. The attenuation of optical fibers refers to the loss of energy of the light beam, which occurs when passing through a fiber in form of absorption and scattering. In order to reduce the signal level on a glass fiber line fiber attenuators are used to increase the damping. Mainly on short distances the installation of an attenuator may be necessary, so the high transmission power does not override the recipient.
Best Attenuation Values
All BlueOptics SFA21BK2 2dB LC/PC Fiber Optic Attenuators have a low input loss and a high return loss. Further optimization of the return loss by adjusting the polish (UPC or 8°APC) is possible. By default BlueOptics SFA21BK2 2dB LC/PC Fiber Optic Attenuators are available in the attenuation stages 1, 2, 3, 5, 7, 10, 15, 20, 25 and 30dB and are designed for working in temperature ranges from -40°C to +75°C.
Highest Quality Components
For lossless transmissions exclusively branded fibers from well-known manufacturers such as Corning, Fujikura or YOFC are used in the production process of BlueOptics SFA21BK2 2dB LC/PC Fiber Attenuators. All installed connectors are manufactured by brand manufacturers such as Amphenol, Diamond, Nissin Kasei or Reichle & De-Massari with highly reliable BlueOptics Zirconia ceramic ferrule and achieve a lifetime of up to 1500 mating cycles.
Error-free Transmission
BlueOptics SFA21BK2 2dB LC/PC Fiber Attenuators are tested after production with interferometer and Optical-Time-Domain-Reflectometry (OTDR) to ensure the best quality. A measurement protocol of the input loss and return loss values is included with every shipped BlueOptics SFA21BK2 2dB LC/PC Fiber Attenuator.
BlueOptics SFA21BK2 2dB LC/PC Fiber Attenuators meet the Telcordia Requirements GR-326-Core 4.4.
Industrial Standards
BlueOptics SFA21BK2 2dB LC/PC Fiber Attenuator are manufactured to meet generally accepted industry standards and norms and are equipped with a flame-retardant LSZH jacket. In case of a fire thus creates a very low smoke emission in comparison to PVC coated Fiber Attenuators. Furthermore no halogen is released.
BlueOptics SFA21BK2 2dB LC/PC Fiber Attenuators meet the following Norms: IEC-61034, IEC-754-1, IEC 60332-1, IEC 60332-3, IEC/EN 60950 and RoHS.
BlueOptics© SFA21BK2 2dB Fiber Optic Attenuator for single-mode (9/125µm) fiber links G.652.D (from 1270nm to 1610nm) from CBO, with LC/PC Simplex connector and highly reliable ceramic ferrule. The attenuation of optical fibers refers to the loss of energy of the light beam, which occurs when passing through a fiber in form of absorption and scattering. In order to reduce the signal level on a glass fiber line fiber attenuators are used to increase the damping. Mainly on short distances the installation of an attenuator may be necessary, so the high transmission power does not override the recipient.
Best Attenuation Values
All BlueOptics SFA21BK2 2dB LC/PC Fiber Optic Attenuators have a low input loss and a high return loss. Further optimization of the return loss by adjusting the polish (UPC or 8°APC) is possible. By default BlueOptics SFA21BK2 2dB LC/PC Fiber Optic Attenuators are available in the attenuation stages 1, 2, 3, 5, 7, 10, 15, 20, 25 and 30dB and are designed for working in temperature ranges from -40°C to +75°C.
Highest Quality Components
For lossless transmissions exclusively branded fibers from well-known manufacturers such as Corning, Fujikura or YOFC are used in the production process of BlueOptics SFA21BK2 2dB LC/PC Fiber Attenuators. All installed connectors are manufactured by brand manufacturers such as Amphenol, Diamond, Nissin Kasei or Reichle & De-Massari with highly reliable BlueOptics Zirconia ceramic ferrule and achieve a lifetime of up to 1500 mating cycles.
Error-free Transmission
BlueOptics SFA21BK2 2dB LC/PC Fiber Attenuators are tested after production with interferometer and Optical-Time-Domain-Reflectometry (OTDR) to ensure the best quality. A measurement protocol of the input loss and return loss values is included with every shipped BlueOptics SFA21BK2 2dB LC/PC Fiber Attenuator.
BlueOptics SFA21BK2 2dB LC/PC Fiber Attenuators meet the Telcordia Requirements GR-326-Core 4.4.
Industrial Standards
BlueOptics SFA21BK2 2dB LC/PC Fiber Attenuator are manufactured to meet generally accepted industry standards and norms and are equipped with a flame-retardant LSZH jacket. In case of a fire thus creates a very low smoke emission in comparison to PVC coated Fiber Attenuators. Furthermore no halogen is released.
BlueOptics SFA21BK2 2dB LC/PC Fiber Attenuators meet the following Norms: IEC-61034, IEC-754-1, IEC 60332-1, IEC 60332-3, IEC/EN 60950 and RoHS.
